| Machine type | 7DCM – 1 year warranty 7DCL – 3 year warranty |
| Form factor | 1U rack-mount |
| Processor | One Intel processor. Choose from:
|
| Chipset | Intel Raptor Lake PCH-S C266 |
| Memory | Four DIMM sockets supporting Lenovo TruDDR5 DIMMs at 4800 MHz (Xeon processors) or 4800 MHz (Pentium processors). Support ECC UDIMMs. |
| Memory maximum | Up to 128 GB using 4x 32 GB UDIMMs. |
| Memory protection | Error-correcting code (ECC) |
| Disk drive bays | Available configurations:
In addition, the SR250 V3 supports two M.2 drives installed in an M.2 adapter which is installed in PCIe slot. |
| Maximum internal storage |
|
| Storage controller |
|
| Optical drive bays | No support. Use an external optical drive. |
| Tape drive bays | No support |
| Network interfaces | Two integrated Gigabit Ethernet 1000BASE-T ports (RJ-45) based on Broadcom BCM5720 embedded controller, one can be shared with XCC for systems management. Third dedicated Gigabit Ethernet port for XCC systems management. |
| PCI Expansion slots | Two PCIe slots depending on the riser selected:
Note: Slimline x8 connector to support onboard NVMe (PCIe 4.0) or CFF RAID card |
| Ports |
|
| Cooling | Four non-hot-swap system fans |
| Power supply | Model dependent choices:
|
| Hot-swap parts | Hard drives and hot-swap power supplies |
| Systems management | Operator panel with status LEDs. XClarity Controller 2 (XCC2) embedded management, XClarity Administrator centralized infrastructure delivery, XClarity Integrator plugins, and XClarity Energy Manager centralized server power management. Optional XCC2 platinum to enable premium functions. |
| Security features | Power-on password, administrator’s password, Trusted Platform Module, supporting TPM 2.0. Optional lockable front bezel for physical security. |
| Video | G200 graphics with 16 MB memory, integrated into the XCC2. For use with local Administrator functions (not designed for workstation use). Maximum resolution is 1920×1200 32bpp at 60Hz. |
| Operating systems supported | Microsoft Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware ESXi. See the Operating system section for specifics. |
| Limited warranty | Three-year or one-year (model dependent) customer-replaceable unit and onsite limited warranty with 9×5 next business day (NBD). |
| Service and support | Optional service upgrades are available through Lenovo Services: 4-hour or 2-hour response time, 6-hour fix time, 1-year or 2-year warranty extension, software support for Lenovo hardware and some third-party applications. |
| Dimensions | Width: 434.4 mm (17.1 in.), height: 43 mm (1.7 in.), depth: 561 mm (22.1 in.). See Physical specifications for details. |
| Weight | Maximum configuration: 12.3 kg (27.1 lb) (3.5” config) or 11.44 kg (2.5” config). |
