DESCRIPTION :
| All Specifications | |||
| Display | |||
| Screen Size | 27 inch | ||
| Panel Type | IPS | ||
| Backlight Technology | LED backlight | ||
| Resolution (max) | 3840×2160 | ||
| Brightness (typ) | 350nits | ||
| Brightness (peak)(HDR) | 350nits | ||
| HDR | HDR10 | ||
| Native Contrast | 1300:01:00 | ||
| Viewing Angle (L/R) (CR>=10) | 178/178 | ||
| Response Times (GtG) | 5 ms | ||
| Refresh Rate (Hz) | 60 | ||
| Color Gamut | 100% Rec.709 ,100% sRGB | ||
| Picture Mode | Animation ,CAD/CAM ,Darkroom ,HDR ,Low Blue Light ,Rec.709 ,sRGB ,User | ||
| Aspect Ratio | 16:09 | ||
| Display Colors | 1.07 billion colors | ||
| PPI | 163 | ||
| Display Screen Coating | Anti-Glare | ||
| Color Temperature | 5000K ,6500K ,9300K ,User Define | ||
| Gamma | 1.8 – 2.6 | ||
| HDCP | 2.2 | ||
| OSD Language | Arabic,Chinese (simplified),Chinese (traditional),Czech,Deutsch,English | ||
| French,Hungarian,Italian,Japanese,Korean,Netherlands,Polish,Portuguese,Romanian,Russian,Spanish,Swedish | |||
| AMA | Yes | ||
| Screen Size | 27 | ||
| Panel Type | IPS | ||
| Backlight Technology | LED backlight | ||
| Viewing Angle (L/R;U/D) (CR>=10) | 178/178 | ||
| Display Area(mm) | 596.74(H) x 335.66(V) | ||
| Pixel Pitch (mm) | 3:43:12 | ||
| DCR (Dynamic Contrast Ratio) | 20M:1 | ||
| Audio | |||
| Built-in Speaker | 2Wx2 | ||
| Headphone Jack | Yes | ||
| Built-in Speaker | 2Wx2 | ||
| Headphone Jack | Yes | ||
| Power | |||
| Voltage Rating | 100 – 240V | ||
| AC Switch | Yes | ||
| Power Supply | Built-in | ||
| Power Consumption (normal) | 24W | ||
| Power Consumption (max) | 80W | ||
| Power Consumption (sleep mode) | 0.5W | ||
| Voltage Rating | 100 – 240V | ||
| AC Switch | Yes | ||
| Dimension and Weight | |||
| Tilt (down/up) | -5˚ – 20˚ | ||
| Swivel (left/right) | 45˚/ 45˚ | ||
| Pivot | 90˚ | ||
| Height Adjustment Stand | 140mm | ||
| Dimensions (HxWxD) (mm) | 426.7 – 547.52 x614x237.9 | ||
| Dimensions (HxWxD) (inch) | 16.8 – 21.5×24.1×9.3 | ||
| Dimensions (HxWxD) (w/o Base) (mm) | 367.9×614.0x57.2 | ||
| Dimensions (HxWxD) (w/o Base) (inch) | 14.5×24.1×2.2 | ||
| Net Weight (kg) | 8.2 | ||
| Net Weight (lb) | 18 | ||
| Net Weight (w/o Base) (kg) | 5.7 | ||
| Net Weight (w/o Base) (lb) | 12.6 | ||
| VESA Wall Mount | 100×100 mm | ||
| Dimensions (HxWxD mm) (w/o Base) | 367.9 x 613.8 x 58.81 | ||
| Dimensions (HxWxD mm) | H: 548.31 x 613.8 x 230.71 | ||
| L: 427.5 x 613.8 x 230.71 | |||
| CTN Dimensions (HxWxD mm) | 686-225 -494 | ||
| Net Weight (kg) (without stand) | 5kg | ||
| Net Weight (kg) | 7.7Kg | ||
| Gross Weight (kg) | 9.9Kg | ||
| Tilt (down/up) | -5˚ – 20˚ | ||
| Swivel (left/right) | 45˚/45˚ | ||
| Pivot | 90˚ | ||
| Height Adjustment (mm) | 140 | ||
| Connectivity | |||
| HDMI (v2.0) | 1 | ||
| DisplayPort (v1.4) | 1 | ||
| MiniDisplayPort (v1.4) | 1 | ||
| DisplayPort out (MST) | YES | ||
| Daisy Chain Technology | DP out (MST) | ||
| USB Type B ( Upstream ) | 2 | ||
| USB 3.1 ( Downstream ) | 4 | ||
| HDMI | HDMI (v2.0a)x1 | ||
| DisplayPort | DisplayPort (v1.4) x1 | ||
| Mini DisplayPort | MiniDisplayPort (v1.4)x1 | ||
| DP out | DP out(MST) | ||
| USB 3.0 Hub | USB Downstream x 4 | ||
| USB 3.0 Hub | USB Upstream x 2 | ||
| Eye Care | |||
| Flicker-free Technology | YES | ||
| Low Blue Light | YES | ||
| Brightness Intelligence (B.I.) | YES | ||
| Flicker-Free Technology | YES | ||
| Environmental Standards | |||
| Energy Star | 8.0 | ||
| TCO Certified | 8 | ||
| EPEAT | Bronze | ||
| Certification | |||
| TUV Certificate | Flicker-free ,Low Blue Light | ||
| Solidworks | YES | ||
| calman verified | YES | ||
| Pantone Validated | YES | ||
| Professional | |||
| Factory Calibration Report | YES | ||
| Delta E | <= 3 (avg) | ||
| Animation mode | YES | ||
| CAD/CAM mode | YES | ||
| Darkroom mode | YES | ||
| KVM Switch | YES | ||
| DualView | YES | ||
| Auto Pivot | YES | ||
| PIP/PBP | YES | ||
| Factory Calibration Report | YES | ||
| Daisy Chain Technology | DP out (MST) | ||
| Software | |||
| Display Pilot | Yes | ||
| Monitor | |||
| Product Color | Gray | ||
| Picture Mode | REC.709 / sRGB / HDR/CAD/CAM / Animation / Low Blue Light / Dark Room / User | ||
| HDR | HDR10 | ||
| Gamma | 1.8 – 2.6 | ||
| Wall Mount | Yes | ||
| AMA | Yes | ||
| Display Screen Coating | Anti-Glare | ||
| Compliant Standards | |||
| TCO Certified | Yes | ||
| Compatibility | |||
| Mac Compatible | Yes | ||
| Windows Compatible | Windows 10, Windows 8.1, Windows 8, Windows 7 | ||
| Solidworks | Yes | ||
